| Battery type |
Lithium iron phosphate (LiFePO₄) |
| Rated capacity |
2.0096kWh |
| Capacity of a single battery cell |
314Ah |
| Battery cell lifespan |
11000 cycles@(25℃, 100%DOD, 0.5P, @70%SOH) |
| Working environment temperature |
Charging: 0℃ - 40℃; Discharge: -20℃ - 40℃ |
| Store the ambient temperature |
-20℃ to 60℃ |
| Environmental altitude |
≤3000m |
| Environmental humidity range |
10% - 90% |
| Protection grade |
IP20 |
| Weight |
18.3kg (net weight) |
| Size |
L360W285H430mm (including outer box)/L285W210H311mm (excluding outer box) |
| Rated power |
1000W |
| The input voltage range of the mains power supply |
200 - 240[VAC]@typical value |
| The input frequency range of the mains power |
50Hz/60Hz@typical value |
| Mains charging power |
1000W |
| AC output voltage |
200 - 240VAC@typical value (bypass mode)/230[VAC]@typical value (inverter mode) |
| Working frequency |
50Hz/60Hz@typical value |
| Photovoltaic input voltage |
12 - 50 [VDC] |
| Maximum input current of photovoltaic |
20A |
| Maximum input power of photovoltaic |
450W |
| AC AC socket |
Australia standard/China standard/British standard/European standard/American standard/South African standard/Universal standard |
