| Project |
Specification |
Remarks |
| Nominal capacity of the product (0.2C) |
608Ah |
|
| Rated voltage |
51.2V |
Working voltage |
| Nominal energy |
31.1296kWh |
|
| Internal resistance |
≤60mΩ |
|
| Maximum charging voltage |
58.4V |
|
| Discharge cut - off voltage |
46V |
|
| Standard charging current |
200A |
|
| Standard discharge current |
152A |
|
| Maximum continuous discharge current |
152A |
|
| Battery size |
800mm630mm600mm |
|
| Weight |
About 352 kilograms |
Subject to actual measurement |
| Working temperature (CC/CV) |
Standard 0℃ - 45℃
Discharge:20℃ - 55℃
Storage:20℃ - 45℃ |
|
| Transportation capacity |
20 - 50% |
SOC |
